Number of input channels

2

Number of output channels

4

Peak total output all channels driven

10800 W

Peak output voltage per channel

153 V

Max output current per channel

49 A peak

16 ohms

660 W

8 ohms

1300 W

4 ohms

2300 W 1

2 ohms

2350 W 1

All channels driven into optimal impedance interval

> 2700 W into 2.4 - 3.2 ohms

8 ohms

4600 W

4 ohms

4700 W

Bridged into optimal impedance interval

> 5400 W into 4.8 – 6.2 ohms

THD + N 20 Hz - 20 kHz for 1 W

< 0.05 %

THD + N at 1 kHz and 1 dB below clipping

< 0.04 %

Dynamic range with analog inputs

>112 dB

Frequency response (1 W into 8 Ohm, 20 Hz - 20 kHz)

+/- 0.05 dB

Common Mode Rejection (CMR)

>74 dB, 20 Hz to 20 kHz

Internal Sample Rate / Data path

96 kHz / 32 bit floating point

Product propagation delay (straight path analog server input -> amp)

1.61 ms

Product propagation delay AES 96 kHz / analog input

1.68 ms

THD + Noise

0.00003 %, 20 Hz - 20 kHz, unweighted

Inputs

2 inputs x 2 link

Input sensitivity settings

+12 or +26 dBu

THD + Noise

0.00022 %, typical at 1 kHz unweighted at +26 dBu headroom setting

THD + Noise

0.00033 %, typical at 20 Hz and 20 kHz unweighted at +26 dBu headroom setting

Adjustable Inter-Sample Voltage Peak Limiter (ISVPL)

17.8 - 153 V, step size 0.1 V

Current Average Limiter (CAL) > 300 ms

25 Arms

MaxRMS (rms voltage limiter)

Yes

MaxPeak (peak voltage limiter)

Yes

Output attenuator

-Inf to 0 dB, step size 0.25 dB

Supported sample rates

48, 96 kHz

Support redundant paths

Yes

Flexible topology

yes

Network latency

0.8, 1.3 and 4 ms

AES / EBU / I/O (input + link)

2 x 3-pin XLR

Analog, 2-channel I/O (input + link)

4 x 3-pin XLR, electronically balanced

Output connectors

Neutrik speakON (1 x NLT8, 2 x NLT4) or 4 Binding Posts (pairs)

Auto 10/100, Auto Uplink

2 x RJ45 etherCON

Control and monitoring interface

Via Ethernet for Lake Controller software, or DLM (the 3rd party protocol)

Detachable mains cord

Neutrik PowerCon rated at 250V/32A

Cooling

Two fans, front-rear airflow, temperature controlled speed

Display

2.5 inch, daylight readable LCD

Fault/Warning/Limit/Clip indicators

RGB LEDs and detailed fault description on display

Mute and soft function buttons

8 provided

Standby Power button

On/Standby

Meter button

Toggles through meter views

Menu

Provides a menu driven interface for full function front panel control

Rotary Encoder

Yes

Exit Button

Provides a “back” function

Operating voltage

140 - 265 V / 70 - 135 V 2

Soft start / Inrush power

Yes / max. 5 A

Power Average Limiter (PAL)

Yes

Power Factor Correction (PFC)

No

Breaker Emulation Limiter (BEL)

No

Under Voltage Limiter (UVL)

No

Rack rail to rear panel

W: 483 mm (19”), H: 88 mm (2 U), D: 386 mm (15.2”)

Weight

13.5 kg (30 lbs)

Finish

Black painted steel chassis with black painted steel / aluminum front
