CVR Pro Line-array Modules 24 kW SET

CVR Pro Line-array Modules 24 kW SET se compune din:

TOP 1 (Link to Top2)	TOP 3 (Link to Top4)	PA 1	Procesor	Ex PA 3
TOP 2	TOP 4	PA 1	MID/High	Sub 3 (Ground)
SUB 1	SUB 2	PA 2	LOW	Sub 4 (Ground)

Component	Nr Bucati	Descriere de baza
CVR Pro Audio Line Array W-8	4	Power handling: LF 1200W (RMS), 2400W (Prog), 4800W (Peak) MF 600W (RMS), 1200W (Prog), 2400W (Peak) HF 200W (RMS), 400W (Prog), 800W (Peak) Frequency response: 52 Hz - 20 kHz +/- 3 dB Sensitivity (1W @ 1M): LF 104 dB, MF 107 dB, HF 111 dB Max SPL (Peak/1M): LF 135 dB, MF 135 dB, HF 134 dB LF section: 2 x 12" neodymium woofer with 3" coil Nominal impedance: 8 ohm MF section: 4 x 6.5" neodymium MF with 2" coil Nominal impedance: 8 ohm HF section: 2 x 3" neodymium compression driver with 75 mm titanium diaphragm Nominal impedance: 16 ohm
CVR Pro Audio Bass Cabinet T-182	4	Type: Dual-drivers, sub-bass system Power handling: 1600W (RMS), 3200W (Prog), 6400W (Peak) Frequency response: 30 Hz - 120 Hz +/- 3 dB Sensitivity: 115 dB (1W @ 1M) Max SPL: 147 dB (Peak/1M) Components: 2 x 18" (460 mm) woofers, 4" (100 mm) coil Nominal impedance: 4 ohm
CVR Pro Audio Amplifier PA-2202	2 + 1 cadou	8 ohm stereo power: 2 x 2200W 4 ohm stereo power: 2 x 4000W 8 ohm bridged mono power: 8000W 4 ohm bridged mono power: 12000W Frequency response: 20 Hz-25 kHz +/- 0.5 dB
CVR Pro Audio Processor PRO-240	1	Model: PRO-240 Configuration: 2 in 4 out 24-bit, 48 kHz sampling rate, ∑-△ AD/DA converter, 32-bit DSP chip Input processing includes: gain, mute, noise gate, high-cut, low-cut, 8-parameter EQ, phase, delay Output processing includes: crossover, 5-parameter EQ, gain, mute, compressor/limiter, phase, delay Every input and output can be matrix-assigned flexibly Adjustable PEQ frequency, gain and bandwidth, styles: Peak, H-Shelve, L-Shelve Styles of all high-cut, low-cut filter and distributor units: Butterworth, Linkwitz-Riley, Bessel. Choice slope is from -6 dB/Oct to -48 dB/Oct Adjustable compressor/limiter threshold, ratio, attack time and release time Adjustable threshold, attack time, release time of all noise gate All delay modules delay time can reach over 682 ms Parameter setting of every channel can be copied Inter-put signal generator, output options: pink noise, white noise, 20 Hz - 20 kHz adjustable sine wave and adjustable signal range 2 x 20 word LCD, backlight and key-press incorporate design, unique one key-press process method 32 user presets;
Flight case for amp rack - 12U	1	Hard Case 12 U
Cables	SET	2x8-Core Link Cable (10 Feet) LC-8C-10F 2x8-Core Link Cable (3 Feet) LC-8C-3F 2x4-Core Speaker Cable (15 Feet) SC-4C-15F 6 x XLR Patch Cable (1.5 Feet) PC-XLR-1.5F 2x XLR Patch Cable (3 Feet) PC-XLR-3F
Pin For Line Array W-8	20	Sistem de prindere ax
Flying Hardware for Line Array W-8	2	Dolly
Stairville PD-332	1	Power Distributor 32A CEE

Detalii Tehnice:

CVR Pro Audio Line Array W-8

The W-8 features two 12" woofers, four 6.5" midrange speaker units, and two 3" high-performance low-distortion neodymium compression drivers with an innovative horn design. The result is a line array system that can deliver up to 8000 watts of clean, detailed sound in a variety of large venues, outdoor shows, and commercial events.

Specifications

• Type: Line array system
• Power handling:
  • LF 1200W (RMS), 2400W (Prog), 4800W (Peak)
  • MF 600W (RMS), 1200W (Prog), 2400W (Peak)
  • HF 200W (RMS), 400W (Prog), 800W (Peak)
• Frequency response: 52 Hz - 20 kHz +/- 3 dB
• Sensitivity (1W @ 1M): LF 104 dB, MF 107 dB, HF 111 dB
• Max SPL (Peak/1M): LF 135 dB, MF 135 dB, HF 134 dB
• LF section: 2 x 12" neodymium woofer with 3" coil
• Nominal impedance: 8 ohm
• MF section: 4 x 6.5" neodymium MF with 2" coil
• Nominal impedance: 8 ohm
• HF section: 2 x 3" neodymium compression driver with 75 mm titanium diaphragm
• Nominal impedance: 16 ohm
• Output section: 3-channel
• Dispersion pattern: 110 deg H x 7.5 deg V
• Speaker cables: LF 1(+) 1(-), 2(+) 2(-). MF 3(+) 3(-). HF 4(+) 4(-)
• Input connectors: 2 x Neutrik NL8
• Recommended crossover:
• LF 60 Hz - 600 Hz
• MF 600 Hz - 1.8 kHz
• HF 1.8 kHz - 20 kHz
• Array design: Arrays of fewer than 3 will provide poor dispersion control and are neither recommended nor supported
• Rigging system: Please refer to the W-8 user manual before any operation
• Enclosure: Birch plywood
• Finish: Waterproof, wear-resistant textured black paint
• 1100 mm W x 405 mm H x 595 mm D
• 43.3 in W x 15.9 in H x 23.4 in D
• 1170 mm W x 475 mm H x 665 mm D (0.37 cbm)
• 46.1 in W x 18.7 in H x 26.2 in D
• Dimensions:
• Package dimensions:
• Net weight: 60 kg / 132.3 lb
• Gross weight: 64 kg / 141.1 lb

CVR Pro Audio Bass Cabinet T-182

For a serious audio setup, you’ll need a high-powered, versatile bass cabinet that can hang with the big boys. The T-182 is a professional sub-bass system designed for large-scale shows. It features twin 800-watt 18” driver units, and is suspension engineered for maximum linear excursion. The twin woofers are housed in a bandpass box to deliver earth-shaking, bass-bumping energy. Partner this bass cabinet with CVR line array systems to provide the best sound for your events.

Specifications

• Type: Dual-drivers, sub-bass system
• Power handling: 1600W (RMS), 3200W (Prog), 6400W (Peak)
• Frequency response: 30 Hz - 120 Hz +/- 3 dB
• Sensitivity: 115 dB (1W @ 1M)
• Max SPL: 147 dB (Peak/1M)
• Components: 2 x 18" (460 mm) woofers, 4" (100 mm) coil
• Nominal impedance: 4 ohm
• Speaker cables: 1(+) 1(-)
• Input connectors: 2 x NL4MP Speakon
• Enclosure: Plywood
• Finish: Black paint
• Dimensions:
  • 1135 mm W x 640 mm H x 790 mm D
  • 44.7 in W x 25.2 in H x 31.1 in D
• Package dimensions:
• 1215 mm W x 720 mm H x 870 mm D (0.76 cbm)
• 47.8 in W x 28.3 in H x 34.3 in D
• Net weight: 89 kg / 196.2 lb
• Gross weight: 95 kg / 209.4 lb

CVR Pro Audio Amplifier PA-2202

With smart engineering, innovative features and efficient design, the PA-2202 is built for clear, untroubled sound in a variety of venues. Its low distortion and great noise-to-signal ratio make it a real beauty in the world of power amplifiers. A powerful beauty that is--delivering up to 4000 watts per channel on 4 ohm speakers and a whopping 8000 on bridged mono power. And for all you touring musicians, the PA series is designed compact and lightweight with protective features to ensure a long, road-worthy life.

Specifications

• 8 ohm stereo power: 2 x 2200W
• 4 ohm stereo power: 2 x 4000W
• 8 ohm bridged mono power: 8000W
• 4 ohm bridged mono power: 12000W
• Frequency response: 20 Hz-25 kHz +/- 0.5 dB
• THD + N (rated power, 4 ohm / kHz): < 0.1%
• Signal-to-noise ratio: > 100 dB
• Input sensitivity: 20 K ohm balanced / 10 K ohm unbalanced
• Output connectors: Speakon (Neutrik)
• Power requirement: 110 V - 120 V, 50 - 60 Hz
• Airframe dimension:
  • 483 mm W x 88 mm H x 377 mm D
  • 19 in W x 3.5 in H x 14.8 in D
• Package dimension:
• 575 mm W x 145 mm H x 565 mm D
• 22.6 in W x 5.7 in H x 22.2 in D
• Net weight: 13.5 kg / 29.8 lb
• Gross weight: 15.5 kg / 34.2 lb

CVR Pro Audio Processor PRO-240

The PRO-240 can help you get the most out of your live sound setup with its comprehensive list of audio control and sound-enhancement features. Using the latest advancements in sonic technology, this sound processor is designed for convenient control and rapid operation so you can get clear, professional sound with the greatest efficiency.

Specifications

• Model: PRO-240
• Configuration: 2 in 4 out
• 24-bit, 48 kHz sampling rate, ∑-△ AD/DA converter, 32-bit DSP chip
• Input processing includes: gain, mute, noise gate, high-cut, low-cut, 8-parameter EQ, phase, delay
• Output processing includes: crossover, 5-parameter EQ, gain, mute, compressor/limiter, phase, delay
• Every input and output can be matrix-assigned flexibly
• Adjustable PEQ frequency, gain and bandwidth, styles: Peak, H-Shelve, L-Shelve
• Styles of all high-cut, low-cut filter and distributor units: Butterworth, Linkwitz-Riley, Bessel. Choice slope is from -6 dB/Oct to -48 dB/Oct
• Adjustable compressor/limiter threshold, ratio, attack time and release time
• Adjustable threshold, attack time, release time of all noise gate
• All delay modules delay time can reach over 682 ms
• Parameter setting of every channel can be copied
• Inter-put signal generator, output options: pink noise, white noise, 20 Hz - 20 kHz adjustable sine wave and adjustable signal range
• 2 x 20 word LCD, backlight and key-press incorporate design, unique one key-press process method
• 32 user presets; status and every preset can be saved and adjusted separately, with code protecting function
• With PC, you can remote control through USB and RS232 connectors
• 256 units linkable by RS485, and do remote link controlling by center-control equipment
• Power supply: AC 110 V / 220 V, 50 Hz / 60 Hz
• Product dimension:
  • 482 mm H x 232 mm W x 44 mm D
  • 19 in H x 9.1 in W x 1.7 in H
• Shipping dimension:
• 605 mm H x 310 mm W x 110 mm D
• 23.8 in H x 12.2 in W x 4.3 in D
• Net weight: 4.1 kg / 9 lb
• Gross weight: 5 kg / 11 lb

Flight Case 12U For Amps FC-12U

Flight case for amp rack - 12U

2x 8-Core Link Cable (10 Feet) LC-8C-10F

8-core link cable (30m)

2x8-Core Link Cable (3 Feet) LC-8C-3F

8-core link cable (1m)

2x4-Core Speaker Cable (15 Feet) SC-4C-15F

4-core speaker cable (45m) with connectors.

6 x XLR Patch Cable (1.5 Feet) PC-XLR-1.5F

XLR patch cable (0,5m)

2x XLR Patch Cable (3 Feet) PC-XLR-3F

XLR patch cable (1m

20 x Pin For Line Array W-8/W-9

Pin for line array W-8/W-9

2x Flying Hardware for Line Array W-8/W-9

Flying hardware for line array W-8 and W-9

Stairville PD-332 Power Distributor 32A CEE,

Tri-Phase Power Distributor. Professional made with digital, Volt- & Amp-Meter. Power Input: thomann 1x 32A CEE, Power Output: 6x 16A EU socket, 1x 32A CEE socket, Protection circuit breaker on each phase, Additional circuit breaker for residual current Fi 32A 4 pole 0.03A,, Digital Voltage Meter and Amp-Meter for each phase on the front side. Made for thomann 19" rack installations., Dimensions: 482 x 134 x 257 mm (LxHxW), Weight: 8,2 kg
