PA Rack III SET

PA Rack III SET este un "PA ca la carte" dupa modelul clasic, extrem de flexibil, cu o ptere instalata de 6 kW. Ideal pentru aplicatii LIVE, poate fi adaptat unei largi configuratii de speakere (inclusiv line-array). Configuratia de baza ramane insa cea bazata pe subwoofere si top-uri, fiind extrem de eficient datorita procesarilor auxiliare din care mentionam urmatoarele functii de baza:

- Fx processing, multiefect processing: Yamaha SPX 2000

- GEQ, elimina totodata frecventele nedorite (anti-feed-back prin metoda clasica de taiere) identificate cu Pink Noise Generator si self audio-anayzer, limitator, booster/atenuator: Behringer FBQ6200HD

- Compresor, Limitator, Crossover, Delay, procesor de sistem (matrix system controller): Xilica XA-2040

- Booster, Exciter joase, Maximizer dedicat puterii Crown care deserveste subwooferele: BBE Sonic Maximizer 882i

- Gatering,  Powergate - dual noise gate cu 'Peak Punch" function, noise reduction/eliminator: Drawmer DS501

- Power amplifiers, (aux DSP): 2 x Crown XTI6002

Import Germania, 3 ani garantie individuala la toate produsele!!

Detalii tehnice:

Behringer FBQ6200HD, 2x 31 band equalizer with feedback Detection, works as feedback detector, or as an audio analyzer, limiter, Pink Noise Generator, 2x XLR or 6.3mm jack input, 2 x XLR or 6.3mm jack output, 1x XLR Mono Sub starting with x- Over frequency controller, 4U, dimensions (HxWxD) 133 x 483 x 138 mm, weight 2.3 kg

Xilica XA-2040

2x4 Matrix System Controller

• 24 bit AD/DA converter
• 40 ms delay pro input and output
• Crossover, compressor and limiter
• 8-Band PEQ per input and output
• Phase corrector
• 30 Presets
• Connections: RS232, USB
• Password protection
• Format: 19" / 1 HE
• Incl. Programming and control software

Crown XTI6002 Power Amplifier 1200W @ 8 Ohms

• 2 Ohms Stereo (per ch.) 3000W
• 4 Ohms Stereo (per ch.) 2100W
• 8 Ohms Stereo (per ch.) 1200W
• 8 Ohms Bridge-Mono 4200W
• 4 Ohms Bridge-Mono 6000W

There's no debate – when you choose Crown's XTi 2 Series, you're choosing one of the most powerful and innovative amplifiers on the market today. That's because the all-new XTi 2 Series amps continue to set the standard for unmatched performance and value, delivering the goods night after night without breaking a sweat.

Next Generation Features:

• Peakx Plus Limiters provide the ultimate in system performance and protection by allowing full control over threshold, attack, and release
• Enhanced Subharmonic Synth section provides user control over frequency, gain and filter type for system-specific tuning
• 3 User-defined fan mode controls – normal, early and fullspeed – for matching fan performance to a specific application
• New system monitoring provides software visibility of AC line voltage and power supply temperature
• Integrated cast-aluminum handles for easy handling and enhanced durability
• Locking power cord clip provides a secure connection between the amplifier and power cord
• Updated HiQnet Band Manager and System Architect control software
• Increased number of presets to a total of 30; 29 of which are user definable

PERFORMANCE

Input EQ:

6 parametric filters per channel with adjustable Q, ±15 dB boost/cut. Also adjustable high and low shelving filters. This 8-filter EQ section can be bypassed.

Crossover Filters:

Highpass and Lowpass per channel. Butterworth 6/12/18/24 dB per octave. Linkwitz-Riley 24/48 dB per Octave. Also includes ± 15 dB bandpass gain and polarity control.

Output EQ:

8 parametric filters per channel with adjustable Q, ±15 dB boost/cut. This 8-filter EQ section can be bypassed.

Delay:

For signal alignment of driver; 50 mS of total delay.

SubHarmonic Synth:

Takes the low-frequency content of the input signal and "synthesizes" a new signal that is the same as the input signal but one octave lower. The new synthesized signal is then mixed with the original signal to create the effect. New: Users now have control over frequency, gain, and filter type.

Peakx Plus Limiter:

User defeatable limiter that allows users to control Threshold, Attack, and Release times.

Presets:

30 total presets, 29 of which are user-definable.

Sensitivity (for full rated power at 4 ohms):

1.4 Vrms

Frequency Response (at 1 watt, 20 Hz - 20 kHz):

+0 dB, –1 dB

Signal-to-Noise Ratio (below rated 1kHz power at 8 ohms):

100 dB (A weighted)

Total Harmonic Distortion (THD):

Damping Factor 20 Hz to 1 kHz

Crosstalk (below rated power)

20 kHz - 1 kHz: > 70 db

Input Impedance (nominal)

20k ohms balanced, 10k ohms unbalanced

Maximum Input Signal:

+22 dBu typical

AC Line Voltage and Frequency Configurations

100 VAC, 120 VAC, 220-240 VAC 50/60 Hz

AC Line Current:

8.3A; no more than 38W at idle

Operating Temperature:

0°C to 40°C at 95% relative humidity (non-condensing)

Level:

Two front-panel rotary level controls, one for each channel

Power Switch

On/Off switch applies AC power to the amplifier

Sel/Prev/Next Buttons

Three buttons near the LCD screen that are used to access menu items and front panel lockout

LCD Screen

Backlit liquid crystal display that shows preset and processing status

Indicators

Signal Indicator:

Green LED, one per channel, illuminates when a very low-level signal is present at input (may be used for troubleshooting cable runs).

–10 Indicator:

Green LED flashes when output signal exceeds -10 dB below clip.

–20 Indicator:

Green LED flashes when output signal level exceeds -20 dB below clip.

Ready Indicator:

Green LED, one per channel, illuminates when the amplifier is ready to produce audio.

Clip Indicator:

Red LED, one per channel, turns on at the threshold of audible distortion

Temp Indicator:

Red LED, one per channel, illuminates under excessive temperature conditions

Power Indicator:

Blue LED illuminates when the amplifier has been turned on and has power

Input/Output Connectors

Input Connectors:

XLR, one per channel

Link/Out Connector

Loop-thru signal from input connector for linking another amplifier, one per channel.

Output Connectors:

Two Neutrik Speakon NL4MP output connectors. Channel-1 Speakon is wired with Ch. 1 and Ch. 2 outputs for use with optional single 4-conductor cable. Two binding post outputs (in parallel with Speakon connectors).

HiQnet USB Connector

Type B, connects to HiQnet network.

Construction

Chassis:

Steel

Front Panel:

Cast-aluminum

Cooling:

Proportional speed fan with front-to-rear airflow.

Dimensions:

19" (W) x 3.5" (H) x 12.25" (D)

Net Weight:

18.5 lbs (8.4kg)

Shipping Weight:

21.5 lbs (9.8kg)

BBE Sonic Maximizer 882i

BBE Sonic Maximizer 882 -The 882i is a dual-mono Sonic Maximizer that features our fourth generation processing engine and perfectly suited for any studio, PA system, guitar/bass rig or any application that requires balanced connectivity. +23dBu headroom, Hardwire bypass, 1U rackmount.

Drawmer DS501 Powergate - dual noise gate with 'Peak Punch" function, new dual mode ‘tuneable’ Peak Punch processing section, fully variable frequency selector (75Hz-16kHz) for the gated signal's transients, key listen facility, stereo linkable, envelope control, attack, hold, decay, range, high & low pass filters, balanced in & out, imensions 482 x 44 x 200 mm (WxHxD), Weight with packaging incl. 3,4 Kg.

Yamaha SPX 2000, multieffect processor.

Hard case + Cables PATCH SET
